Description
- Horsepower and Torque: 610 Horsepower / 525 FT. LBS. Torque
- Cylinder Heads: Gen III Hemi Apache Aluminum Cylinder Heads
- Compression Ratio: 10.48:1
- Pistons: Forged
Block:
- Engine Manufactured and Machined in the USA!
- NEW “BGE” Hellcat Engine Block
- 4-Bolt Main
- 4.090″ Bore
- 1-Piece Rear Main Seal
Rotating Assembly:
- Forged Steel Crank
- 4.050″ Stroke
- 6.125″ Connecting Rods
- Forged Pistons
- Internally Balanced Front and Rear
Cylinder Heads:
- Gen III Hemi Apache Aluminum Cylinder Heads
- 73cc Chamber
- 2.140″ Intake / 1.650″ Exhaust Valves
Cam Specs:
- Hydraulic Roller Cam
- .610 Intake / .611 Exhaust Lift
- 231 Intake / 255 Exhaust Duration
- @.050-113 Degree Lobe Separation
Ignition Timing:
- Controlled by ECU
Also Includes:
- Harmonic Balancer
- Muscle Car Style – Mid Sump Swap Oil Pan
- Fabricated Intake Manifold
- Fuel Injection
- Throttle Body
- Spark plugs
- Coil
- Timing Cover
- Valve Covers
- Front Accessory Drive with Water Pump, Alternator, Power Steering Pump, and A/C Compressor
- Holley Terminator ECU Controller Kit and Wiring Harness
Notes:
- Features 2013+ 58X reluctor wheel
- 2009+ crankshaft spacing
- 2009+ car timing cover
- VVT locked out
- MDS – eliminated
| KEY SPECS | |
|---|---|
| MFG. Part # | PS426CTFKB |
| Brand | BluePrint Engines |
| Crate Engine Type | Long Block |
| Engine Displacement | 426 cu. in. |
| Horsepower | 610 horsepower |
| Compression Ratio | 10.48:1 |
| Torque | 525 ft./lbs. |
| Camshaft Type | Hydraulic Roller |
| Cylinder Head Material | Aluminum |
| Piston Material | Forged Aluminum |
| Crankshaft Material | Forged Steel |
| Combustion Chamber Volume | 73cc |
| Camshaft Duration (.050 in) | 231° intake / 255° exhaust |
| Camshaft Lift (in) | .610 intake / .611 exhaust |
| Carburetor Included | No |
| Intake Manifold Included | Yes |
| Distributor Included | No |
| Valve Covers Included | Yes |
| Engine Balance | Internal |
| Cylinder Heads Included | Yes |
| Rear Main Seal Style | 1-piece |
| Throttle Body Included | Yes |
| Oil Pan Included | Yes |
| Timing Cover Included | Yes |
| Water Pump Included | Yes |
| Harmonic Balancer Included | Yes |
| Flexplate Included | No |
| Flywheel Included | No |
| Air Cleaner Included | No |
| Spark Plugs Included | Yes |
| Spark Plug Wires Included | Yes |
| Computer Included | Yes |
| Wiring Harness Included | Yes |
