Description
Description:
Horsepower & Torque: 465 Horsepower / 494 FT. LBS. Torque
Compression Ratio: 10:1
Aluminum Heads
Roller Cam
Cast Crank
Forged Pistons
Block:
Hand-Picked Seasoned Magnum Block
Square and Parallel Decked
Align Honed Main Bearing Bore
Cylinders Honed on Computer Controlled Machine to Within .0002 Straightness and Roundness
Cylinders are Sonic Tested for Thickness
2-Bolt Main
4.040″ Bore
2-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Rotating Assembly:
Cast Crankshaft
4.000″ Stroke
Forged Magnum 6.123″ Connecting Rods w/ 150,000 PSI Bolts
Forged Pistons
Externally Balanced Front and Rear
Cylinder Heads:
Kezar’s Perfomance Assembled and Machined Edelbrock 61769 Casting
Aluminum Magnum Pattern Cylinder Heads – 58cc chamber
Aluminum Roller Rockers
2.02″ intake / 1.60″ Exhaust Valves
176cc intake / 75cc Exhaust Runners
Cam Specs:
Cam Type: Roller
.544 Intake / .541 Exhaust Lift
236 Intake / 242 Exhaust Duration
@.050-110 Degree Lobe Separation
Ignition Timing:
34 Degrees Total at 4000 RPM
Also Includes:
Valve Covers
Oil Pan
Timing Cover
Holley 750 cfm Carburetor
Water Pump
Spark Plugs and Wires
Distributor
Water Neck
Thermostat and Thermostat Housing
Fuel Pump and Fuel Line
Harmonic Balancer
Air Cleaner
Front Accessory Drive with Alternator, A/C Compressor, Power Steering Pump, and Water Pump
Performance 727 Transmission with 2200-2600 Stall.
10-inch Torque Converter
Performance Built Transmission
Starter
