Description
Description:
Horsepower & Torque: 390 Horsepower / 410 FT. LBS. Torque
Compression Ratio: 9.2:1
Aluminum Heads
Hydraulic Roller Cam
Cast Crankshaft
Hypereutectic Pistons
Block:
NEW BluePrint Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Passenger Side Dipstick
Drilled and Tapped for Clutch Linkage
Rotating Assembly:
Cast Crankshaft
3.480″ Stroke
Forged 5.700″ Connecting Rods
Hypereutectic Pistons
Internally Balanced Front – Externally Balanced Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – H8002K
64cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
195cc Intake / 75cc Exhaust Runners
Cam Specs:
Hydraulic Roller
.495 Intake / .502 Exhaust Lift
220 Intake / 224 Exhaust Duration
@ .050-114 Degree Lobe Separation
Ignition Timing:
32 Degrees Total at 3500 RPM
Also Includes:
Holley Brawler 670cfm Vacuum Secondary Carburetor w/ Electric Choke
Standard Rotation Long Style Water Pump
Thermostat and Thermostat Housin
Valve Covers
Harmonic Balancer
Spark Plugs
Spark Plug Wires
Water Neck
Fuel Pump
Rear Sump Oil Pan
Timing Cover
Aluminum Intake
HEI Distributor
