Performance Automatic Blue Chip Street Smart Transmission Systems PASS45206

Description

Performance Automatic Blue Chip Street Smart Transmission Systems PASS45206

Brand: Performance Automatic

Manufacturer’s Part Number: PASS45206

Part Type: Automatic Transmissions

Product Line: Performance Automatic Blue Chip Street Smart Transmission Systems

Summit Racing Part Number: PMA-PASS45206

Number of Gears: 4

Bellhousing Bolt Pattern Manufacturer: Chevy

Transmission Shift Pattern: Forward

Valve Body Style: Automatic

Transmission Advertised Horsepower Rating: 650

Torque Converter Included: Yes

Flexplate Included: No

Transmission Controller Included: Yes

Wiring Harness Included: Yes

Transmission Cooler Included: No

Advertised Flash Stall Rating: 2,200-2,400 rpm

Trans-Brake Included: No

Lockup Compatible: Yes

Transmission Pan Style: Stock

Transmission Pan Material: Steel

Transmission Pan Finish: Natural

Input Spline Quantity: 35

First Gear Ratio (Automatic Transmissions): 2.84

Transmission Case Style: OEM

Transmission Case Material: Aluminum

Transmission Case Finish: Black

Transmission Shield Built In: No

Flexplate Shield Built In: No

Fluid Fill Location: Case

Transmission Fluid Included: No

Dipstick Included: Yes

Remanufactured: Yes

Quantity: Sold as a kit.

Notes: Designed for Ford small block Windsor applications. Recommended for applications with 650 hp or less. The included transmission pan is a stock-type steel pan. Package includes the Smart Shift electronic transmission controller and wiring harness.

Performance Automatic Blue Chip Street Smart Transmission Systems

Performance Automatic Blue Chip Street Smart transmission systems are specifically designed for Ford’s Coyote, 572 big block, 2.0L, 2.3L, and 3.5L EcoBoost crate engines, as well as the Ford modular, FE, and small block engines. Rated to handle up to 850 hp, they come complete and ready for a simple bolt-in installation. All components are matched to your specific engine and guaranteed to perform beyond your expectations.

Blue Chip Street Smart systems include:

* Ford’s 4R70W electronically controlled overdrive transmission with many upgrades and internal modifications
* Custom-built, engine specific torque converter
* Updated Smart Shift controller and wiring harness with bump shift/paddle shifter capabilities and full throttle, non-torque managed shifts
* New design bellhousing for the 2.0L, 2.3L, 3.5L, FE, and big block engines
* Hardware and components needed for installation
* 3-year limited warranty
